Barra Lineal LED Integrado - Superficie - DETROIT PLATA -24V- 0,5m - 1m - 1,5m - 2m
PART NUMBER: SL01013-P
Our Professional luminaire linear 24V. - DETROIT PLATA ANONIZADA - is designed for intensive 24-hour uninterrupted use. Our surface bar is manufactured in Europe, a la medida de sus necesidades. Aluminio extruido de 98% de pureza, la fuente lumínica profesional es - SMD2010 de 12W/M - delivery 1188 lumens per meter - 266 Leds/meter. The integrated LED luminaire does not include a 24 V power supply. 2 meters of cable. 3 years warranty. Lead time: 48h (Monday to Friday).
Our diffuser is opal white.
Barra Lineal LED Integrado 24V - Superficie - DETROIT PLATA
Our integrated LED bar is designed for intensive professional use where a high quality of light is required. - INDICE DE RENDIMIENTO CROMATICO +90-The product has a long service life and a good service life.
Our LED linear is a versatile and timeless range, it can be the protagonist in the interior design of a space or adapt to it. Thanks to the various sizes and colors available, it can provide a variety of visual sensations that will define the space from a new perspective.
Available in various lengths and in suspended or ceiling-mounted versions, to adapt to different needs and installation heights. The luminaires, up to 2 meters long, become beautiful traces of light that shape the space.
Our integrated LED profile draws homogeneous lines of light that adapt to a wide variety of spaces with minimal visual impact, solving both general lighting needs and the illumination of vertical and horizontal planes.
Its design combines high transmittance diffusers that provide high visual comfort and energy efficiency.
Our professional linear LED luminaire has a power of 12W/meter.
The light source of our linear LED luminaire incorporates 266 LEDs/meter of high brightness SMD2010 delivering1188Lm/meter; LED diodes incorporate gold wire soldering for longer life.
The integrated LED luminaire includes 2 meters of cable for easy connection. The consumption of the luminaire is 6W for 50cm; 12W for 100cm; 18W for 150cm; and 24W for 200cm. The LED luminaire is made of high purity 6063/6060 aluminum (98%), with UNE EN 755 and UNE EN 12020-1 heat treatment.
The lacquer of the luminaire is of high resistance and qualityThe silver coating is -Qualanod- 15 microns thick for long life. High transmittance diffuser to minimize lumen loss.
Our integrated LED linear bar as it is custom-made, it offers several possibilities to choose between a warmer, neutral or cooler lighting, and several colors to choose from.
The luminaire is manufactured in Europe to the customer's desired size, so this product does not admit product returns, as it is a custom-made product. Our manufacturing time is 48 working hours.
Usos de la Barra Lineal LED Integrado - Superficie - DETROIT PLATA
- Retailers
- Exhibitions
- Industries
- Offices
- Homes
TECHNICAL DATA SHEET
| REFERENCE : | SL01013-P | |
| Rated power : | 6W 0.5m -12W 1m -18W 1.5m-24W 2m | |
| Nominal voltage: | 24V DC | |
| Light temperature: | 3000K-4000K-6000K -RED-GREEN-BLUE | |
| CRI - Color Rendering Index: | 90 | |
| Building Material: | Aluminum +PC | |
| Luminosity-Lm: | 1M:1188Lm/2M: 2376Lm | |
| Type of LEDs: | SMD2010 - 266 Chips/M | |
| Opening Angle (º): | 120º | |
| LED Diode Efficiency (Lm/W): | 150Lm/W | |
| Luminous efficacy (Lm/W): | 100 Lm/W | |
| Certificates: | CE - ROHS |
| IP rating: | IP54 | |
| Estimated Life LED Diode (H): | 50.000 | |
| Dimensions (mm): | L: 0,50m - 1m - 1,5m - 2m | |
| Power Factor (PF): | 0.97 | |
| Working Frequency (Hz): | 50/60Hz | |
| Temperature range (ºC): | -20°C ~ +55°C | |
| Ignition Cycles: | 100.000 | |
| Start-up time (s): | 0,2s | |
| Energy Class (2021-EU-2019/2015): | A+ | |
| Warranty years: | 3 |
